10.1 Inch TFT LCD Touch Display Module 800×1280 Resolution MIPI Interface Wide Viewing Angle
800×1280 Resolution MIPI Interface Capacitive Touch Screen with Wide Viewing Angle
Product Overview
The YVT101VLM-A01 is a high-performance 10.1-inch TFT LCD touch display module designed for industrial control systems, smart home devices, medical equipment, self-service terminals, and embedded display applications.
Featuring an 800×1280 high-resolution display, MIPI interface, and integrated TDDI touch technology, this module combines display and touch functionality into a compact solution while delivering stable performance, excellent image quality, and responsive touch interaction.
With support for up to 10-point capacitive touch, 16.7 million colors, and wide viewing angles, it is an ideal display solution for modern HMI and intelligent device applications.
Key Features
- 10.1-inch TFT LCD touch display module
- 800 × 1280 high-resolution display
- MIPI display interface
- Integrated TDDI touch technology
- Capacitive touch support
- Up to 10 simultaneous touch points
- 16.7 million display colors
- 380 cd/m² typical brightness
- 1000:1 contrast ratio
- Wide viewing angle technology
- Slim and compact module structure
- Designed for embedded and industrial applications
- Customization support available
Technical Specifications
| Item |
Specification |
| Model Number |
YVT101VLM-A01 |
| Display Size |
10.1 Inch |
| Resolution |
800 × 1280 |
| Display Technology |
TFT LCD |
| Display Mode |
Normally Black |
| Active Area |
135.36 × 216.56 mm |
| Module Dimensions |
153.85 × 243.85 × 3.90 mm |
| Brightness |
380 cd/m² (Typ.) |
| Contrast Ratio |
1000:1 (Typ.) |
| Color Depth |
16.7M Colors |
| Display Interface |
MIPI |
| Touch Interface |
I2C |
| Touch Technology |
Capacitive Touch (TDDI) |
| Touch Points |
Up to 10 Points |
| Viewing Angle |
80° / 80° / 80° / 80° |
| Operating Temperature |
-10°C to +50°C |
| Storage Temperature |
-20°C to +60°C |
| Certification |
CE / RoHS |
Product Advantages
Integrated TDDI Technology
The integrated Touch and Display Driver Integration (TDDI) architecture combines touch and display functions into a streamlined design.
Benefits include:
- Reduced system complexity
- Improved signal stability
- Enhanced touch responsiveness
- Simplified product integration
- Lower overall system footprint
High-Resolution Display Performance
With an 800 × 1280 resolution, the display delivers sharp images, clear text rendering, and smooth graphical performance.
Ideal for:
- Industrial user interfaces
- Smart control systems
- Interactive displays
- Embedded visualization devices
Multi-Touch User Experience
Supporting up to 10 simultaneous touch points, the module enables intuitive and responsive interaction.
Advantages include:
- Smooth gesture operation
- Fast response time
- Improved usability
- Enhanced interactive control
Wide Viewing Angle Technology
The display maintains consistent color and image quality from multiple viewing positions.
Benefits include:
- Improved visibility
- Better user experience
- Stable image presentation
- Suitable for shared viewing environments
Compact Mechanical Design
The slim profile and lightweight construction simplify integration into space-constrained products.
Suitable for:
- Portable devices
- Embedded terminals
- Smart control panels
- Industrial equipment
Interface Configuration
| Interface |
Function |
| MIPI |
High-Speed Display Signal Transmission |
| I2C |
Capacitive Touch Communication |
The interface structure supports seamless integration with embedded processors, industrial controllers, and intelligent terminal platforms.
Application Areas
Smart Home Systems
- Home automation panels
- Smart control terminals
- Security management displays
- Intelligent appliance interfaces
Industrial Automation
- Human Machine Interfaces (HMI)
- Industrial control equipment
- Factory automation terminals
- Equipment monitoring systems
Medical Equipment
- Diagnostic instruments
- Healthcare terminals
- Portable medical devices
- Monitoring systems
Commercial Equipment
- Self-service kiosks
- POS terminals
- Retail control systems
- Interactive information displays
Embedded Devices
- IoT control panels
- Smart terminals
- Portable controllers
- Embedded display solutions
Optical Performance
Clear and Stable Image Quality
The combination of high-resolution display technology and a 1000:1 contrast ratio provides:
- Sharp text presentation
- Enhanced image detail
- Better visual depth
- Professional display quality
Balanced Brightness
With 380 cd/m² typical brightness, the module offers excellent readability for indoor and commercial environments.
Suitable for:
- Control panels
- Industrial equipment
- Commercial devices
- Medical systems
Customization Services
To support different project requirements, customization options are available.
Display Customization
- Brightness adjustment
- Optical enhancement
- Color tuning
Touch Customization
- Touch panel structure
- Touch sensitivity optimization
- Cover glass modification
Mechanical Customization
- FPC design adjustment
- Connector customization
- Mechanical dimension optimization
OEM & ODM Support
- Private branding
- Logo customization
- Product adaptation
- Project-specific development
Quality Assurance
Each display module undergoes comprehensive inspection and validation procedures before shipment.
Quality control includes:
- Display performance testing
- Touch functionality verification
- Electrical parameter inspection
- Optical quality assessment
- Mechanical structure inspection
Packaging & Delivery
- Anti-static protective packaging
- Export-standard carton packaging
- Sample order support
- Flexible order quantities
- Global shipping support
Technical Support
Professional engineering support is available throughout the product lifecycle.
Services include:
- Product selection assistance
- Interface integration support
- Customization consultation
- Project development assistance
- Long-term technical cooperation
Why Choose YVT101VLM-A01
The YVT101VLM-A01 combines high-resolution display performance, integrated TDDI touch technology, wide viewing angles, and a compact industrial-grade design into a reliable embedded display solution.
It is an ideal choice for smart home systems, industrial automation equipment, medical devices, self-service terminals, and next-generation embedded display applications requiring stable performance and responsive touch interaction.
